Powering the next generation of business aircraft. Winner of Aviation
Week Network’s 2019 Laureate Award: Business aviation – Propulsion.

10,000 to 20,000 Pound Thrust Class

10Products-14BAE-PW800-Introduction-inline-image-1600x780

The PW800 engine family embodies the latest advances in technology. The PW800 is the most modern, efficient and environmentally responsible engine in its class. It offers double-digit improvements in fuel burn, emissions and noise as compared to the current generation of engines. It also offers 40% less scheduled maintenance and 20% fewer inspections than other engines in its class. It is supported by an exclusive, concierge-level service and advanced digital connectivity. For new generation, long- range business jets.

Exceptional Proven Performance

Sharing the same proven core technology as P&W’s award-winning GTF™ engine, the PW800 sets new standards in aircraft performance and fuel efficiency in the long-range business jet market.

10Products-14BAE-PW800-PerformanceContent-Quiet-card-800x450

Latest technology, exceptional cabin experience, easy maintenance

The PW800 provides an unsurpassed passenger experience, with the low-noise design and low vibration levels ensuring an exceptionally quiet cabin. With 40% less scheduled on-wing maintenance, it is the easiest engine in its class to access and maintain – and it’s backed by our proactive, seamless service and support network.

10Products-14BAE-PW800-PerformanceContent-Sustainability-card-800x450

Sustainability, today and tomorrow

The PW800 over-delivers on reducing the engine’s footprint and moving toward a greener aviation world. Through our revolutionary technological innovations, we’re setting new sustainability standards and driving the whole industry onward.

10Products-14BAE-PW800-PerformanceContent-Future-card-800x450

The future of flying

The PW800 engine has been raising the bar on performance and economics for the long and ultra-long range business jet segments. It delivers the best overall performance, efficiency and quiet operation for high-speed aircraft, thanks to its optimized bypass ratio.

No Limits

By setting new standards in performance, fuel efficiency and dependability, the PW800 engine is ushering in a new era in the long range business jet market.

Bypass Duct Mixer High Pressure Turbine High Pressure Compressor Advanced single-piece fan Talon X Combustor FADEC (Full Authority Digital Engine Control)

Specs

Three PW800 engine models are currently available ranging in thrust from 11,000 to 16,000 pounds

Engines	Thermodynamic thrust class* (Pounds)	Mechanical thrust class* (SHP)	Diameter**(inches)	Length**(inches)
PW812D	13,629	11,367	44	111.2
PW814GA	15,429	14,155	50	130
PW815GA	16,011	15,568	50	130

* Thrusts are approximate values at take-off. Available at sea level, standard day, static conditions, uninstalled.
** Dimensions are approximate values.

Applications (3)

PW812D PW814GA PW815GA

A Personalized Concierge-level Service Experience

Those who operate PW800-powered aircraft expect the best, so we offer quick, effortless and incredibly responsive service backed by a worldwide 24/7 support team so you can fly at a moment’s notice.
