The right choice for light jets

900 to 3,000 Pound Thrust Class


At the heart of an exciting range of very light and light jets, the PW600 engine is compact, fuel efficient and easy to maintain, offering excellent operating economics.

The PW600 is a two-spool engine with a two-stage high pressure compressor driven by a single-stage high pressure turbine and a single-stage low pressure turbine driving a robust, advanced technology fan. A high efficiency reverse-flow combustor ensures low emissions and fuel consumption. A high efficiency exhaust mixer further contributes to the engine family's low fuel burn and noise. Furthermore, the latest Full-Authority Digital Engine Control (FADEC) provides reduced pilot workload and advanced engine health monitoring/diagnostics, assuring a high standard in aircraft dispatch availability. Special attention to “maintenance by design” enables fast access to engine externals. The result is a compact, lightweight design powering an impressive line of very light business jets.


Three PW600 engine models are currently available ranging in thrust from 950 to 1,750 pounds.

 Engines   Thermodynamic thrust class* (Pounds)  Mechanical thrust class* (SHP) Diameter**(inches)   Length**(inches)
 PW617F Series   2,050   1,780   17.6   49
 PW615F Series   1,695   1,460   16   49.5
 PW610F Series   1,200   950   14   46

* Thrusts are approximate values at take-off. Available at sea level, standard day, static conditions, uninstalled.
** Dimensions are approximate values.
